The diameter and length of Aluminum Extrusion

In the aluminum extrusion process, the diameter and length of the aluminum rod (also known as the ingot or billet) are determined according to the tonnage of the extrusion machine, the design capacity, and the required final product specifications. Here is some general information:

Aluminum rod diameter

Diameter: The diameter of the aluminum rod usually varies according to the rated pressure of the extruder. For example, a 1000-ton extruder might be suitable for an aluminum rod with a diameter of 127mm. As the tonnage of the extruder increases, the diameter of the aluminum rod will also increase accordingly. For large extruders, such as 10,000-ton equipment, the diameter of the aluminum rod may reach 380mm or larger.

Aluminum rod length

Length: The length of the aluminum rod can vary according to production needs and the design of the equipment. In some cases, the standard length may be about 6 to 7 meters, but this value can be adjusted according to the specific process requirements. For example, in the example mentioned above, a 6-inch (about 152mm diameter) 1600-ton short-stroke aluminum extruder used a billet length of 780 mm.

Please note that the size of the aluminum rod in the actual application needs to be matched to the specific extrusion process and is affected by the specific model of the extrusion machine, the mold design, the desired product shape and size, and other factors. Different manufacturers and different extrusion lines may have different standards and restrictions.
